These are the 1.80mm Single Shoulder nickel plated spring bars. Each size spring bar is sold in a pack of 10, allowing you to decide the size of the replacement spring bar you need. Simply select the size you need from the drop down menu above.
- Come in packages of 10
- Nickel plated spring bars
- Single shoulder
- 1.80mm regular diameter
- Come in 11 different lengths: 6 mm, 8 mm, 10 mm, 11 mm, 13 mm, 14 mm, 16 mm, 18 mm, 19 mm, 21 mm, and 22 mm
Part Number |
Fits Lug Width |
Compressed Length |
Overall Length |
Body Length |
Tip Diameter |
82.232 |
1/4' / 6mm |
6.3mm |
7.9mm |
6.2mm |
.80mm |
82.234 |
5/16" / 8mm |
7.7mm |
9.1mm |
7.7mm |
.70mm |
82.236 - Replaced by Steel |
3/8" / 10mm |
9.4mm |
11.6mm |
9.4mm |
.70mm |
82.238 |
7/16" / 11mm |
11.0mm |
12.5mm |
11.0mm |
.80mm |
82.240 |
1/2" / 13mm |
12.4mm |
14.8mm |
12.5mm |
.80mm |
82.242 |
9/16" / 14mm |
13.7mm |
15.7mm |
13.7mm |
.70mm |
82.244 |
5/8" / 16mm |
15.7mm |
17.9mm |
15.7mm |
.80mm |
82.246 |
11/16" / 18mm |
17.9mm |
20.0mm |
17.9mm |
.80mm |
82.248 - Steel |
3/4" / 19mm |
18.8mm |
20.4mm |
18.8mm |
.80mm |
82.250 |
13/16" / 21mm |
20.6mm |
22.7mm |
20.6mm |
.80mm |
82.252 |
7/8" / 22mm |
22.3mm |
24.5mm |
22.3mm |
.80mm |
82.256 - Steel |
15/16" / 24mm |
23.8mm |
26.1mm |
23.8mm |
.80mm |
