These are the replacement spring bars for the 1.27 mm extra thin double flanged spring bar assortment. Each size spring bar is sold in a set of 10, allowing you to decide the size of the replacement spring bar you need. Simply select the size you need from the drop down menu above.
- Sold in packages of 10
- Stainless steel spring bars
- Double flanged
- 1.27 mm extra thin diameter
- Come in 10 different lengths: 6 mm, 8 mm, 10 mm, 11 mm, 13 mm, 14 mm, 16 mm, 18 mm, 19 mm, and 21 mm
- **Note** Sizes are determined by the compressed length of the spring bar
Part Number |
Fits Lug Width |
Compressed Length |
Overall Length |
Body Length |
Tip Diameter |
82.123.1 |
6mm / 1/4" |
7.9mm |
9.6mm |
5.8mm |
.55mm |
82.123.2 |
8mm / 5/16" |
7.9mm |
9.8mm |
5.6mm |
.70mm |
82.123.3 |
10mm / 3/8" |
10.9mm |
13.2mm |
8.1mm |
.70mm |
82.123.4 |
11mm / 7/16" |
11.1mm |
13.6mm |
8.3mm |
.70mm |
82.123.5 |
13mm / 1/2" |
12.6mm |
15.4mm |
9.6mm |
.70mm |
82.123.6 |
14mm / 9/16" |
13.9mm |
16.5mm |
10.8mm |
.70mm |
82.123.7 |
16mm / 5/8" |
16.2mm |
19.2mm |
12.9mm |
.70mm |
82.123.8 |
18mm / 11/16" |
17.7mm |
20.9mm |
14.6mm |
.70mm |
82.123.9 |
19mm / 3/4" |
18.8mm |
22.1mm |
15.6mm |
.70mm |
82.123.10 |
20mm / 13/16" |
20.9mm |
24.5mm |
17.8mm |
.70mm |
